Double the capacity, designed for larger operations.
Ext. 40’ x 8’ x 9’6”
Int. 38’ x 7’6” x 8’4”
Operated on 460V 3-phase or 240V 3-phase.
-20F to 80F (at 100F ambient)
Ground level access or delivered on a chassis for dock height.
Tare Weight
(Including Reefer)
4,440 kg
10,362 lb
Tare Weight
(Excluding Reefer)
4,080 kg
9,303 lb
Payload
30,560 kg
66,800 lb
MGW
35,000kg
77,162 lb
Length
12.192 mm
40’-0”
Width
2,438 mm
8’-0”
Height
2,896 mm
9’-6”
Length
11,588 mm
38’-0”
Width
2,280 mm
7’-6”
Height
2,537 mm
8’-4”
Width
2,290 mm
7’-6”
Height at Sill
2,569 mm
8’-5”
Height – Cargo Access
2,502 mm
8’-3”
Area
67 m³
2367 ft³
Width
1,029 mm
3′-5″
Height
120 mm
0′-5″
Center Distance
3,174 mm
10′-5″
Width
N/A
N/A
Height
N/A
N/A
Center Distance
N/A
N/A
Have questions? Get answers to common questions about SeaCube’s products and support.
SeaCube offers 20 Foot and 40 Foot refrigerated containers for flexible, scalable cold storage. Whether you need a compact unit or expanded capacity, our containers deliver reliable, portable refrigeration with precise temperature control, ready to perform wherever you need them.
